Specification
Wireless Specifications
Antenna Type 5 external high-gain antennas
Button 1 x WPS/Reset button
Data Rate 5 GHz: 1201 Mbps, 2.4 GHz: 300 Mbps
Frequency Bands CE: 2.4G (2412-2472 MHz), 5G (5180-5240 MHz) FCC: 2.4G (2412-2462 MHz), 5G (5150-5250 MHz, 5725-5850 MHz)
Transmission Power CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz & 5 GHz)
Wireless Standards IEEE 802.11ax/ac/n/a (5 GHz), IEEE 802.11n/b/g (2.4 GHz)
Security & Firewall
Firewall & Security ICMP, TCP, UDP flood attack defense; Port Forwarding, DMZ Host, UPnP
Parental Controls Tenda App integration, Client Filter, Remote Web Management
Special Features
VPN Support PPTP, L2TP, IPSec Transparent Transmission (Client/Server)
Wireless Security WPA2-PSK, WPA3-SAE, WPA3-SAE/WPA2-PSK
Power
Power Input AC 100-240V ~ 50/60Hz
Connectivity & Compatibility
Interface 1 x 10/100/1000 Mbps WAN port 3 x 10/100/1000 Mbps LAN ports
Environmental Specifications
Operating Temperature Temperature: 0℃ to 40℃ Humidity: 10%-90% RH non-condensing
Regulatory Compliance
Certifications CE, FCC, RoHS
Physical Design & Dimensions
LED Indicators 1 x LED
Weight 244 x 56 x 200 mm (L x W x H)
Color White
Output
Power DC 12V 1A
Warranty & Support
Warranty 01-year official warranty
